Machine Type

Digital Colour Cut - Sheet Press

Core Functions

Print

Processor Speed

1.8GHz Dual

Control Panel

25.6cm(10.1inch)

Memory

6GB

Storage

SSD 1TB

Interface Connection (Network)

Standard: 1000Base-T/100Base-TX/10Base-T

Paper Input (Standard)

Standard: 1 000 sheets (Suction Feeding)

Optional: POD Deck (1 000 + 1 000 + 2 000) Sheets x 2 (Suction Feeding with Escape Tray)

Paper Supply Capacity (A4, 80g/m2 (gsm))

Maximum: 9 000 sheets

Finishing Capabilities

Collate, Group, Offset, Staple, Saddle Stitch, Hole Punch (multiple patterns), Document Insertion, Fold (C-, Z-, Half, Double parallel, Accordion-Z fold), Trimming

Supported Media Types

Thin, Plain, Recycled, Color, Thick Coated, Embossed, Bond, Trancparency, Label, Pre Punched, Letterhead, Index, Vellum, Transparent film, Translucent film,

Supported Media Sizes

SRA3S、A3S、A4L、A4S、B4S、B5L、B5S、 330.2 x 482.6mm(13 x 19inch)(S), 304.8 x 457.2mm(12 x 18inch)(S), 279.4 x 431.8mm(11 x 17inch)(S), LGLS, LTRL, LTRS, EXECL, 8KS, 16KL, 16KS, Custom Size（182.0 x 182.0mm - 330.2 x 487.7mm)

Supported Media Weights

60-500g/m2 (gsm)

Dimensions (W x D x H)

2 691 x 1 165 x 1 456mm

Installation Space (W x D)

5 218 x 1 875mm (Engine, Deck, Finisher)

Weight

1 065kg (Engine, PS, FS & BP)

Printing Method

Colour Laser Beam Printing

Print Speed

CL:135 A4 pages/min, BW:130 A4 pages/min

Recommended Monthly Print Volume

up to 1.2million A4 Pages/month

Maximum Monthly Print Volume

2.4million A4 Pages/month

Alignment Tolerance

0.5mm

Print Resolution (dpi)

2 400 x 2 400dpi

Page Description Languages

PS3,PCL6

Optional/Standard

Optional

Name

Fiery- Part of imagePRESS Printer Family- E9000

Print Resolution (dpi)

1200 x 1200, 600 x 600

Page Description Language(s)

PS3/PCL6

Memory

32GB

Hard Disk Drive

480GB
2 x 2TB

Processor Speed

Intel Xeon 4214 Dual 3.20GHz, 12Core

System

FS500 Pro

Fonts

138 PS fonts

Supported Operating Systems

Windows 8.1 32 and 64 bit / Windows10 32 and 64 bit / Windows11 / Windows 2012 R2 64 bit only/ Windows Server 2016 64bit / Windows Server 2019 64bit / Windows Server 2022 64bit /MAC OS ( 10.14, 10.15, 11, 12 )

Interface

2 x Ethernet (1000Base-T/100Base-TX/10Base-T), USB3.0 x 7

Network Protocols

TCP/IP (FTP, SMTP, POP, HTTP, SNMP, LDAP, SMB,
LPD, IPP, WS-Discovery, Bonjour, Direct Mobile Printing

Port 9100, 802.1X, DHCP, DNS, NTP)

Direct Print

PDF2, EPS, TIFF, JDF1.8/JMF

VDP

PPML3.0, PDF/VT-1, PDF/VT1, VPS, FreeForm Plus

Fiery Print Controller Standard Features

Fiery HyperRIP 1-step color management/ Zero-touch recalibration / Fiery JobExpert / Fiery Graphic Arts Pro Package/ Fiery Impose/ Fiery Compose/ EFI IQ/ Fiery Edge™/ Image Enhance Visual Editor/ Fiery FreeForm™ Create/ Fiery Spot-On™/ Fiery Hot Folders and Virtual Printers/ Fiery JobFlow™ Base/ GUI enablement

Fiery Print Controller Options

Fiery JobFlow / Fiery JobMaster / Fiery Color Profiler Suite (Software only) / ES-3000 Spectrophotometer / Fiery Disk Drive Security Kit / Fiery NX Station LS / GL

HW Platform

NX Premium

Dimensions (W x D x H)

235mm x 464mm x 527mm

Weight

17kg

Staple Finisher

Staple Finisher AF1

Upper Tray (A) Capacity:
A4/A4R/A5R/A3/SRA3/ 330.2 x 482.6mm(13 x 19inch) 1 000 sheets (52 - 300g/m2 (gsm)) / 200 sheets (301 - 350g/m2(gsm))

Lower Tray (B) Capacity:
A4 4,000 sheets (52-80g/m2(gsm))/ 3,000 sheets (80.1-300g/m2(gsm))
A4R 2,000 sheets (52-300g/m2(gsm))

A3 1,500 sheets (52-g/m2(gsm))

SRA3 1,000 sheets (52-g/m2(gsm))

Any size 200 sheets (301-350g/m2(gsm))

Paper Weight: 52 to 350g/m2(gsm)
Staple Position: Corner, Double
Staple Capacity: A4: 100 sheets, A3/A4R: 50 sheets
Dimensions (W x D x H): 800mm x 792mm x 1 239mm
Weight: Approx. 130kg
Power: 220-240V, 50-60Hz, 8A

Booklet Finisher

Booklet Finisher AF1

Tray Capacity / Paper Weight / Staple Position / Staple

Capacity: same as Staple Finisher AF1
Booklet stitch paper size: A3, A4R, SRA3, 330.2 x 482.6mm(13 x 19inch), Free size (210 x 279.4 mm to 330.2 x 487.7mm)
Booklet stitch paper weight: Body sheet 52-220g/m2(gsm), Cover sheet 64-300g/m2(gsm)
Booklet stitch staple capacity: 25 sheets (52-80g/m2(gsm), include cover)
Non Staple Folded Bunch Capacity: up to 5 sheets (60 to 105m2(gsm)
Dimensions (W x D x H): 800mm x 792mm x 1 239mm

Weight: Approx. 180kg

Power: 220-240V, 50-60Hz, 8A

Paper Folding - K1

Supported Folding Type: Z-Fold, Accordion Z-Fold, C-Fold, Half-Fold, Double Parallel Fold
Acceptable Paper Type: Thin, Plain, Recycled, Colour,  Bond

Acceptable Paper Sizes:

Z-Fold : A3, A4R , B4

Accordion Z-Fold, C-Fold, Half-Fold, Double Parallel Fold: A4R

Acceptable Paper Weight:
Z-Fold, Accordion Z-Fold, C-Fold, Half-Fold :60 to 105m2(gsm)

Double Parallel Fold : 60 to 90m2(gsm)

Power Source: From the Finisher
Dimensions (W x D x H): 336 × 793 × 1 190 mm
Weight: Approx. 71kg

Document Inserter - R1

Number of trays: 2

Tray Capacity:
Upper Tray: 200 Sheets (80 m2 (gsm))
Lower Tray: 200 Sheets (80 m2 (gsm))

Acceptable Paper Type: Thin, Plain, Recycled, Colour, Thick, Pre-punched, Letterhead, Bond, Coated, Tab, Tracing, Textured

Acceptable Paper Sizes: SRA3, A3, A4, A4R, B4, B5, B5R,  Custom size (182.0 × 182.0 mm to 330.2 × 487.7mm)

Acceptable Paper Weight: 60 to 300 m2(gsm)
Power Source: 100-240V/50/60Hz
Dimensions (W x D x H): 336 x 793 x 1 407mm (width excluding document tray)
Weight: Approx. 61 kg

Hole Puncher

(Requires either the STAPLE FINISHER-AF1 or BOOKLET FINISHER-AF1)

Two or Four Holes
Punch Hole type:
BT1: 2 holes and 4 holes (FRN) selectable,
BU1: 4 holes (SWE)

Punch Paper Weight: 60-300 g/m2(gsm)
Punch Paper Size:
2 holes: A3, A4, A4R, Free size (182 x 182 mm to 297 x 432.0mm excluding 203 x 257mm to 297 x 270mm)
4 holes: A3, A4, Free size (257 x 182mm to 297 x 432mm)

Booklet Trimmer - F1

Requires Booklet Finisher-AF1

Trim Width: 2-28mm
Trim Thickness: Up to 50 sheets (include cover)
Paper Weight: 60 to 300g/m2(gsm)
Chip tray capacity: Approx. 5 000 sheets (Trim width 20mm, A4, 80 gsm)
Dimensions (W x D x H): 2 095 mm (including joint, conveyor and output tray) x 790mm x 1 040mm
Weight: Approx. 178kg (including conveyor and output tray)

Toner Cartridge/s

Toner T14 BK/C/M/Y

Staple Cartridge

STAPLE-N1 - for Stapling (3 x 5,000 pcs) (for Staple Finisher-AF1 and Booklet Finisher-AF1)

STAPLE-P1 - for Saddle Stitching (2 x 5,000 pcs) (for Booklet Finisher-AF1)
