Machine Type

A3 Monochrome Laser Multifunctional

Core Function

Print, Copy, Scan, Send, Store and Optional Fax

Processor

1.75GHz Dual-Core Processor

Control Panel

Standard: 25.6cm (10.1in) TFT LCD WSVGA Color Touch panel
Optional: 26.4cm (10.4in) TFT LCD SVGA Color Upright Touch panel.

Memory

Standard: 3.0GB RAM

Hard Disk Drive

Standard*1: 320GB (available disk space: 250GB)
Optional: 250GB, 1TB

Mirroring Hard Disk Drive

Optional

Interface Connection

Network
Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n)
Optional: NFC, Bluetooth Low Energy

Others
Standard: USB 2.0 (Host) x1, USB 3.0 (Host) x1, USB 2.0 (Device) x1;
Optional: Serial Interface, Copy Control Interface

Paper Supply Capacity (A4, 80g/m²)

Standard: 4 200 sheets
100-sheet Multi-purpose tray x 1
1 500-sheet Paper Deck x 2
550-sheet Paper Cassette x 2

Maximum: 7 700 sheets (with POD Deck Lite-C1 or Paper Deck Unit-E1)

Paper Output Capacity (A4, 80g/m²)

250 sheets (with Copy Tray-R2).
Maximum: 5 000 sheets (High-Volume Stack mode "ON" with Staple Finisher-W1 PRO or Booklet Finisher-W1 Pro)

Finishing Capabilities

With options: Collate, Group, Offset, Staple, Saddle Stitch, Hole Punch, Eco Staple, Staple On Demand, Document Insertion, Z-fold, Half-fold, C-fold, Accordion-Z fold, Double Parallel-fold, Trimming

Supported Media Types

Multi-purpose tray:
Thin, Plain, Recycled, Colour, Heavy, Tracing, Bond, Transparency, Labels, Pre-punched, Letterhead, Tab*2

Paper Decks (Right/Left):
Thin, Plain, Recycled, Colour, Heavy, Bond, Pre-punched, Letterhead

Paper Cassettes (Upper/Lower):
Thin, Plain, Recycled, Colour, Heavy, Bond, Pre-punched, Letterhead, Tab*2

Supported Media Sizes

Multi-purpose tray:
Standard size: SRA3, A3, A4, A4R, A5*3, A5R, A6R*4, B4, B5, B5R
Custom size: 100.0 x 148.0mm to 330.2 x 487.7mm
Free Size : 100.0 x 148.0mm to 330.2 x 487.7mm

Paper Decks (Right/Left):
Standard size: A4, B5

Paper Cassettes (Upper/Lower):
Standard size: SRA3, A3, A4, A4R, A5R, B4, B5, B5R
Custom size: 139.7 x 182.0mm to 330.2 x 487.7mm

Supported Media Weights

Multi-purpose tray: 52 to 256g/m²
Paper Decks (Right/Left): 52 to 220g/m²
Paper Cassettes (Upper/Lower): 52 to 220g/m²
Duplex: 52 to 220g/m²

Warm-up Time

Quick Startup Mode: 4 seconds or less*5
From Deep Sleep Mode: 60 seconds or less
From Power On: 60 seconds or less*6

Dimensions (W x D x H)

Standard (including 1-pass DADF and flat touch panel): 670 x 770 x 1 185mm
With optional Upright touch panel:
1 170 x 770 x 1 252mm

Installation Space (W x D)

Basic: 1 533 x 1 353mm (with Multi-purpose tray/upper-right cover open + Front Cover open + Copy Tray)
Fully configured: 5 068 x 1 409mm (with POD Deck Lite-C1 + Document Insertion Unit-N1 + Multifunction Professional Puncher-B1 + Paper Folding Unit-J1 + Booklet Finisher-W1 Pro + Booklet Trimmer-F1 + Main unit Front Cover open)

Weight

Standard: approx. 221 kg*7
With optional Upright touch panel: approx. 225 kg*8

Print Speed

iR-ADV DX 8705:
up to 105 pages per minute (A4), up to 54 pages per minute (A3), up to 76 pages per minute (A4R), up to 105 pages per minute (A5R)

iR-ADV DX 8795:
up to 95 pages per minute (A4), up to 50 pages per minute (A3), up to 69 pages per minute (A4R), up to 95 pages per minute (A5R)

iR-ADV DX 8786:
up to 86pages per minute (A4), up to 44 pages per minute (A3), up to 63 pages per minute (A4R), up to 86 pages per minute (A5R)

Print Resolution (dpi)

1 200 x 1 200

Page Description Languages

Standard: UFR II (standard)
Optional: PCL 6, Adobe® PostScript® 3™

Direct Print

Supported file types: PDF, EPS, TIFF/JPEG and XPS

Printing from Mobile and Cloud

AirPrint, Mopria, Google Cloud Print, Canon Business Print, and uniFLOW Online

A range of software and MEAP-based solutions are available to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements.
Please contact your sales representative for further information.

Fonts

PS fonts: 136 Roman
PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WTJ / K / S / T*9 (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts*10

Print Features

Secured Print, Secure Watermark, Header/Footer, Page Layout, Two-sided Printing, Mixed Paper Sizes/ Orientations, Front/Back Covers, Toner Reduction, Poster Printing, Forced Hold printing, Print Date, Scheduled Printing, Printing Using a Virtual Printer

Operating System

UFRII:
Windows®7/8.1/10/Server 2008/Server 2008 R2/Server 2012/Server 2012 R2/Server 2016/Server 2019, MAC OS X (10.10 or later)

PCL:
Windows®7/8.1/10/Server 2008/Server 2008 R2/Server 2012/Server 2012 R2/Server 2016/Server 2019

PS:
Windows®7/ 8.1/10/Server 2008/Server 2008 R2/Server 2012/Server 2012 R2/Server 2016/Server 2019, MAC OS X (10.10 or later)

PPD:
Windows®7/8.1/10, MAC OS X (10.9 or later)

As of July, 2019.

Copy Speed

iR-ADV DX 8705:
up to 105 pages per minute (A4), up to 54 pages per minute (A3), up to 76 pages per minute (A4R), up to 105 pages per minute (A5R)

iR-ADV DX 8795:
up to 95 pages per minute (A4), up to 50 pages per minute (A3), up to 69 pages per minute (A4R), up to 95 pages per minute (A5R)

iR-ADV DX 8786:
up to 86 pages per minute (A4), up to 44 pages per minute (A3), up to 63 pages per minute (A4R), up to 86 pages per minute (A5R)

First-Copy-Out Time (A4)

Approx. 2.7s or less

Copy Resolution (dpi)

600 x 600

Multiple Copies

Up to 9 999 copies

Copy Density

Automatic or Manual (9 Levels)

Magnification

Variable zoom: 25% to 400% (1% Increments)
Preset reduction/enlargement: 25%, 50%, 61%, 70%, 81%, 86%, 100% (1:1), 115%, 122%, 141%, 200%, 400%

Copy Features

Preset R/E Ratios by Area, Two-Sided, Density Adjustment, Original Type Selection, Interrupt Mode, Book to Two Pages, Two-sided Original, Job Build, N on 1, Add Cover, Insert Sheets, Different Size Originals, Page Numbering, Copy Set Numbering, Sharpness, Erase Frame, Secure Watermark, Print Date, Gutter, Print & Check, Negative/Positive, Repeat Images, Merge Job Blocks, Mirror Image, Store in Mail Box, Superimpose Image, Copy ID Card, Skip Blank Pages, Free Size Original, Reserved copy, Copy Sample

Type

Single-pass Duplexing Automatic Document Feeder*11 [2-sided to 2-sided (Automatic)]

Document Feeder Paper Capacity (80g/m²)

Up to 200 Sheets

Acceptable Originals and Weights

Platen: Sheet, Book, and 3-Dimensional Objects

Document Feeder media weight*12:
1-sided scanning: 38 to 220g/m² (Black & White, Colour)
2-sided scanning: 38 to 220g/m² (Black & White, Colour)

Supported Media Sizes

Platen maximum scanning size: up to
297.0 x 431.8mm

Document Feeder media size:
A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, B6R
Custom size: 70.0 x 139.7mm to 304.8 x 431.8mm

Scan Speed (Black & White /Colour, A4)

1-sided Scanning:
135/135 (300 x 300dpi, send), 135/80 (600 x 600dpi, copy)

2-sided Scanning:
270/270 (300 x 300dpi, send), 165/90 (600 x 600dpi, copy)

Scan Resolution (dpi)

Scan for Copy: 600 x 600
Scan for Send: (Push) 600 x 600 (SMB/FTP/WebDAV/IFAX), (Pull) 600 x 600
Scan for Fax: 600 x 600

Pull Scan Specifications

Colour Network ScanGear2. For both TWAIN and WIA
Supported OS: Windows®7 / 8.1 / 10 / Server2008 / Server2008 R2 / Server2012 / Server2012 R2 / Server 2016

Scan Method

Push Scan, Pull Scan, Scan to Box, Scan to Advanced Box, Scan to Network, Scan to USB Memory Key, Scan to Mobile device, Scan to cloud (uniFLOW Online)

Destination

Standard: E-mail/Internet FAX (SMTP), SMB3.0, FTP, WebDAV, Mail Box
Optional: Super G3 FAX, IP Fax

Address Book

LDAP (2000) / Local (1600) / Speed dial (200)

Send Resolution (dpi)

Push: up to 600 x 600
Pull: up to 600 x 600

Communication Protocol

File: FTP (TCP/IP), SMB3.0 (TCP/IP), WebDAV
E-mail/I-Fax: SMTP, POP3

File Format

Standard: TIFF, JPEG, PDF (Compact, Searchable, Apply policy, Optimize for Web, PDF/A-1b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word)

Universal Send Features

Original Type Selection, Two-sided Original, Book to Two Pages, Different-size Originals, Density Adjustment, Sharpness, Copy Ratio, Erase Frame, Job Build, Delayed Send, Preview, Job Done Notice, File Name, Subject/Message, Reply-to, E-mail Priority, TX Report, Original Content Orientation, Skip Blank Pages

Maximum Number of Connection Lines

4

Modem Speed

Super G3: 33.6kbps
G3: 14.4kbps

Compression Method

MH, MR, MMR, JBIG

Resolution (dpi)

400 x 400 (Ultra Fine), 200 x 400 (Super Fine), 200 x 200 (Fine), 200 x 100 (Normal)

Sending / Receiving Size

"Sending: A3, A4, A4R, A5*13, A5R*13, B4, B5*14, B5R*13
Receiving: A3, B4, A4, A4R, A5R , B5, B5R

Fax Memory

Up to 30 000 pages (2 000 jobs)

Speed Dials

Maximum 200

Group Dials / Destinations

Maximum 199 dials

Sequential Broadcast

Maximum 256 addresses

Memory Backup

Yes

Fax Features

Sender's Name (TTI), Selecting the Telephone Line (when sending fax), Direct Send, Delayed Send, Preview, Job Done Notice, TX Report, Interrupt Transmission, Sequential Broadcasting, Password/Subaddress Sending, Confidential Mailbox, 2 on 1 Log

Mail Box (Number supported)

100 User Inboxes
1 Memory RX Inbox
50 Confidential Fax Inboxes
Maximum 30 000 Pages (2 000 jobs) Stored

Advanced Box

Communication Protocol: SMB or WebDAV
Supported Client PC: Windows® 8.1/10
Concurrent Connections (Max.): SMB:64, WebDAV:3

Advanced Box Available Disc Space

Standard: 16GB
(With option: maximum 480GB)

Advanced Box Features

Authentication for Advanced Box Log-in, Sort Function, Printing a PDF File with a Password, imageWARE Secure Audit Manager Support, Search, File Preview, Authentication Management, Open to public, URI TX, Backup/Restore

Authentication and Access Control

Standard: User Authentication (Picture Login, Picture and PIN Login, Card Login, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online Express (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login), Access Management System (Access Control)

Document Security

Print Security (Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print*15), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS, Adobe LiveCycle® Rights Management ES2.5 Integration), BOX Security (Mail Box Password Protected, Advanced Box Access Control), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support), Document Tracking (Secure Watermark)

Network Security

TLS 1.3, IPSec, IEEE802.1X authentication, SNMP V3.0, Firewall Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/Wired LAN), Disabling Unused Functions (Enabling/Disabling Protocols/Applications, Enabling/Disabling Remote UI, Enabling/Disabling USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Prohibit the execution of files stored in Advanced Box in the MFP, Scan and Send -Virus Concerns for E-mail Reception

Device Security

Protecting HDD Data (HDD Data Encryption (FIPS140-2 Validated), HDD Data Overwrite Erase, HDD Lock), Standard HDD Initialize, Trusted Platform Module (TPM), Job Log Conceal Function, Protecting MFD Software Integrity, Checking MFD Software Integrity (Verify System at Startup, Runtime Intrusion Detection)
Optional: IEEE2600.2 (Common Criteria Certification) (TBD)

Device Management and Auditing

Administrator Password, Digital Certificate And Key Management, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Image Data Logging, Security Policy Setting

Operating Environment

Temperature: 10 to 30ºC
Humidity: 20 to 80 % RH (Relative Humidity)

Power Source

220-240V, 50/60Hz, 10A

Power Consumption

Maximum: Approx. 2,400W
Standby: Approx. 217W*16
Sleep mode: Approx. 0.9W*17

Toner Cartridge/s

NPG-53 Black Toner

Toner (Estimated Yield @ 5% Coverage)

70 000 Pages

Tracking and Reporting

Universal Login Manager (ULM)
uniFLOW Online Express

Remote Management Tools

iW Management Console
eMaintenance
Content Delivery System

Scanning Software

Network ScanGear

Optimisation Tools

Canon Driver Configuration Tool
NetSpot Device Installer

Platform

MEAP (Multifunctional Embedded Application Platform)

Document Publishing

IW DESKTOP

Optional/Standard

Optional on all models

Name

imagePASS-Y3 V1.1 (Server)

Print Resolution (dpi)

1 200 x 1 200, 600 x 600

Print Resolution (dpi)

1 200 x 1 200, 600 x 600

Standard Page Description Language(s)

PCL6, Adobe® PostScript® 3™

Memory

8GB (2 x 4GB)

Hard Disk Drive

500GB SATA

Processor

Intel Pentium G4400 (3.3 GHz)

System

FS350Pro

Fonts

PS: 138 Fonts
PCL: 113 Fonts

Supported Operating Systems

Windows 7 64 bit / Windows 8.1 64 bit / Windows 10 64 bit / Windows Server 2008 R2 64bit only / Windows Server 2012 64bit only (Only Printer driver support) / Windows Server 2012 R2 64bit only / Windows Server 2016 R2 64 bit only, MAC OS (10.11,10.12, 10.13, 10.14)

Interface

2 x Ethernet (1000Base-T/100Base-TX/10Base-T)
USB 3.0 x 2 (rear), x 3 (front on Fiery Quick Touch TM)
USB 2.0 x 4 (rear)

Network protocols

TCP/IP (FTP, SMTP, POP, HTTP, SNMP, LDAP, SLP, SMB, LPD, IPP, WS-Discovery, Bonjour, Direct Mobile Printing, Port9100, SNTP, 802.1X, DHCP, DNS, NTP)

Direct Print

PDF1.7, EPS, TIFF6, JDF1.4/JMF (Optional)

VDP

FreeForm v1, v2.1, PPML, PDF/VT-1, PDF/VT-2, Creo VPS

Fiery Print Controller Standard Features

Fiery Command WorkStation6 / Paper Catalog / Fiery Remote Scan / Fiery Hot Folders & Virtual Printers / Fiery JDF

Fiery Print Controller Options

Fiery Impose / Fiery Compose / Fiery Impose and Compose / Removable HDD kit / Image Viewer

HW Platform

NX One

Base OS

Windows 10 IoT Enterprise 2019 LTSC

Power Source

AC100-240V, 50Hz/60Hz, 3.0A (100V) - 1.5A (240V)

Maximum Power Consumption

53W

Dimensions (W x D x H)

203 x 248 x 384mm

Weight

Server unit only: Approx. 5.9kg

Paper Deck Unit-E1

Paper Capacity: 3 500 sheets (80g/m²)
Paper Type: Thin, Plain, Recycled, Colour, Heavy, Bond, Pre-punched, Letterhead
Paper Size: A4, B5
Paper Weight: 52 to 256g/m²
Power Source: from the Main Unit
Dimensions (W x D x H): 340 x 630 x 572mm (attached to the main unit)
Weight: Approx. 34kg

POD Deck Lite-C1

Paper Capacity: 3 500 sheets (80g/m²)

Paper Type: Thin, Plain, Recycled, Colour, Heavy, Tracing, Bond, Transparency, Label, Pre-punched, Letterhead, Tab

Paper Size:
SRA3, A3, A4, A4R, A5R, B4, B5, B5R
Custom Size (139.7 x 182.0mm to 330.2 x 487.7mm)

Paper Weight: 52 to 256g/m²

Power Source: 220-240V, 50/60Hz, 1.2A　

Dimensions (W x D x H): 633 x 686 x 574mm (attached to the main unit)

Weight: Approx. 68kg

Copy Tray-R2

Provides a simple tray for basic output needs.
Capacity: 250/100 sheets (1-sided/2-sided, 80g/m²)
Dimensions (W x D x H): 420 x 382 x 175mm

Staple Finisher-AC1*18

Tray Capacity (with 80g/m² paper):
Upper Tray:
A4, A5, A5R, A6R, B5: 250 sheets
A3, A4R, B4, B5R: 125 sheets
SRA3: 30 sheets
Mid Tray: Same as upper tray
Lower Tray:
A4, A5, A5R, B5: 3 000 sheets
SRA3, A3, A4R, B4, B5R: 1 500 sheets
A6R: 250 sheets

Paper Weight: 52 to 256g/m²

Staple Position: Corner, Double

Staple Capacity:
A4, B5: 65 sheets (52 to 90g/m²)
A3, A4R, B4: 40 sheets (52 to 90g/m²)

Eco Staple: A3, A4
5 sheets (52 to 64g/m²)
4 sheets (65 to 81.4g/m²)
3 sheets (81.5 to 105g/m²)

Staple On Demand: 65 sheets (52 to 90g/m²)

Power Source: From the main unit

Dimensions (W x D x H): 656 × 623 × 1 195mm (when the extension tray and rotary tray are extended)

Weight: Approx. 36 kg

Booklet Finisher-AC1*18

(Includes the above Staple Finisher-AC1 basic staple specifications.)

Saddle Stitch paper size: A3, A4R, B4, Custom Size (182.0 x 210.0mm to 304.8 x 457.2mm)
Saddle Stitch Staple Capacity: 20 sheets x 10 sets (52 to 81.4g/m²) (including 1 cover sheet up to 256g/m²)
Non Staple Folded Bunch Capacity: 3 sheets (52 to 105g/m²)

 Power Source: From the main unit

 Dimensions (W x D x H): 656 × 623 × 1 195mm (when the extension tray and rotary tray are extended)

Weight: Approx. 60kg

Staple Finisher-X1

Tray Capacity (with 80g/m² paper):
Upper Tray:
A4, A5R, B5: 1 500 sheets
SRA3, A3, A4R, A5, B4, B5R: 750 sheets
A6R: 250 sheets
Mid Tray:
A4, A5R, B5: 250 sheets
A3, A4R, A5, A6R, B4, B5R: 125 sheets
SRA3: 30 sheets
Lower Tray:
A4, B5: 2,500 sheets (Cascade-Load mode)
A4, A5R, B5: 1 500 sheets
SRA3, A3, A4R, A5, B4, B5R: 750 sheets
A6R: 250 sheets

Paper Weight: 52 to 256g/m²

Staple Position: Corner, Double

Staple Capacity:
A4, B5: 100 sheets (52 to 80g/m²)
A3, A4R, B4: 50 sheets (52 to 80g/m²)

Power Source: 100-240V AC, 50-60 Hz, 2.8A

Dimensions (W x D x H): 782 × 765 × 1 040mm (when the extension tray is extended)

 Weight: Approx. 64kg

Booklet Finisher-X1

(Includes the above Staple Finisher-X1 basic specifications.)

Saddle Stitch paper size:
SRA3, A3, A4R, B4, Custom Size (195.0 x 270.0mm to 330.2 x 457.2mm)

Saddle Stitch Staple Capacity:
20 sheets x 5 sets (60 to 81.4g/m²) (including 1 cover sheet up to 256g/m²)

Non Staple Folded Bunch Capacity: 5 sheets (60 to 105g/m²)

Power Source: 100-240V AC, 50-60 Hz, 2.8A

Dimensions (W x D x H): 896 × 765 × 1 040mm (when the extension tray is extended)

Weight: Approx. 110kg

Staple Finisher-W1 PRO

Tray Capacity (with 80g/m² paper):
Upper Tray: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R: 1 000 sheets
Z-Fold: A3, B4: 30 sheets
Half-Fold: A4R 50sheets
Lower Tray:
If the High-Volume Stack Mode is set to "ON":
A4, B5: 4 000 Sheets
A4R, B5R: 2 000 Sheets
SRA3, A3, B4: 1 500 Sheets
If the High-Volume Stack Mode is set to "OFF":
A4, B5: 2 000 Sheets
SRA3, A3, A4R, B4, B5R: 1 000 Sheets

Paper Weight: 52 to 256g/m²

Staple Position: Corner, Double

Staple Capacity: Corner and Double Stapling:
A4, B5: 100 sheets (52 to 80g/m²)
A3, A4R, B4, B5R: 50 sheets (52 to 81.4g/m²)

Power Source: 220-240V/50-60 Hz/8A

Dimensions (W x D x H): 890 × 792 × 1 239mm (when the extension tray is extended)

Weight: Approx. 130kg

Booklet Finisher-W1 PRO

(Includes the above Staple Finisher-W1 PRO basic specifications.)

Saddle Stitch paper size:
SRA3, A3, A4R, B4, Custom Size (210.0 x 279.4mm to 330.2 x 487.7mm)

Saddle Stitch Staple Capacity: 25 sheets
(52 to 80g/m²) (including 1 cover sheet up to 256g/m²)

Non Staple Folded Bunch Capacity: up to 5 sheets (52 to 209g/m²)

Power Source: 220-240V, 50-60 Hz, 8A

Dimensions (W x D x H): 1 060 x 792 x 1 239mm (when the extension tray is extended)

Weight: Approx. 180kg

2/3 Hole Puncher Unit-A1

(Requires either the Staple Finisher-AC1 or Booklet Finisher-AC1)

Two or Three Holes
Acceptable Punch Paper Weight: 52 to 256g/m²
Acceptable Punch Paper Size:
Two holes: A3, A4, A4R, A5, B4, B5, B5R
Three holes: A3, A4, B4, B5

Power Source: From the finisher

2/4 Hole Puncher Unit-A1

(Requires either the Staple Finisher-AC1 or Booklet Finisher-AC1)

Two or Four Holes
Acceptable Punch Paper Weight: 52 to 256g/m²
Acceptable Punch Paper Size:
Two holes: A3, A4, A4R, A5, B4, B5, B5R
Four holes: A3, A4

Power Source: From the finisher

Puncher Unit-BF1

(Requires either the Staple Finisher-X1 or Booklet Finisher-X1)

Two or Three Holes
Acceptable Punch Paper Weight: 52 to 256g/m²
Acceptable Punch Paper Size:
Two holes: A3, A4, A4R, A5
Three holes: A3, A4

Power Source: From the finisher

Puncher Unit-BG1

(Requires either the Staple Finisher-X1 or Booklet Finisher-X1)

Two or Four Holes
Acceptable Punch Paper Weight: 52 to 256g/m²
Acceptable Punch Paper Size:
Two holes: A3, A4, A4R, A5, B5R
Four holes: A3, A4

Power Source: From the finisher

Puncher Unit-BS1

(Requires either the Staple Finisher-W1 PRO or Booklet Finisher-W1 PRO)

Two or Three Holes
Acceptable Punch Paper Weight: 52 to 256g/m²
Acceptable Punch Paper Size:
Two holes: Custom size (182.0 x 182.0mm to 297.0 x 432.0mm)
Three holes: Custom size (240.0 x 182.0mm to 297.0 x 432.0mm)

Power Supply: From the finisher

Puncher Unit-BT1

(Requires either the Staple Finisher-W1 PRO or Booklet Finisher-W1 PRO)

Two or Four Holes
Acceptable Punch Paper Weight: 52 to 256g/m²
Acceptable Punch Paper Size:
Two holes A3, A4, A4R, A5, B4, B5, B5R, Custom size (182.0 x 182.0mm to 297.0 x 432.0mm, excluding 203 x 257mm to 297 x 270mm)
Four holes A3, A4, B4, B5, Custom size
(257.0 x 182.0mm to 297.0 x 432.0mm)

Power Supply: From the finisher

Puncher Unit-BU1

(Requires either the Staple Finisher-W1 PRO or Booklet Finisher-W1 PRO)

Four Holes
Acceptable Punch Paper Weight: 52 to 256g/m²
Acceptable Punch Paper Size:
Four holes A3, A4, A5, B4, B5, Custom size
(257.0 x 182.0mm to 297.0 x 432.0mm)

Power Supply: From the finisher

Multi Function Professional Puncher-B1

(Requires either the Staple Finisher-X1, Booklet Finisher-X1, Staple Finisher-W1 PRO or Booklet Finisher-W1 PRO)

Acceptable Punch Paper Weight:
Bypass: 75 to 256g/m²
Punch: 75 to 256g/m²

Acceptable Punch Paper Size:
Bypass: 100 x 148mm to 330.2 x 487.7mm
Punch: A3, A4, A4R, A5

Supported Punch Dies (optional):
A4: Loose Leaf (2- or 4- hole), Velo Bind (12-hole), Plastic comb (21-hole), Twin Loop (23- or 34- hole), Color Coil (47-hole)

Power Source: 230V, 50Hz, 2.0 A
Dimensions (W x D x H): 445 x 795 x 1 040mm

Weight: 102 kg

Inner Booklet Trimmer-A1

(Requires Booklet Finisher-X1)

Waste Tray Capacity: Approx. 1 500 Sheets
Acceptable Paper Weight: 60 to 256g/m²
Trim Amount: 2 to 20mm
Acceptable Paper Size: SRA3, A3, A4R, B4, Custom size: 195 x 270mm to 330.2x 457.2mm

Power Source: From the finisher

Booklet Trimmer-F1

(Requires Booklet Finisher-W1 PRO)

Booklet Capacity: 10 booklets (booklet size: A4, 50 sheets, 80g/m²)
Acceptable Paper Weight: 52 to 256g/m², 64 to 300g/m² (cover sheet only)
Acceptable Paper Size:
SRA3, A3, A4R, B4, Custom size: 210.0 x 279.4mm to 330.2 x 487.7mm

Trim Amount: 2 to 28mm
Trimming Capacity: up to 25 sheets (50 sheets by Half-Fold) (52 to 80g/m²)
Waste Tray Capacity: Approx. 5 000 Sheets

Power Source: From the Booklet Finisher-W1 PRO

Dimensions: 2 095 x 790 x 1 040mm (including joint)

Weight: Approx. 178kg

Document Insertion Unit-N1

(Requires either the Staple Finisher-X1, Booklet Finisher-X1, Staple Finisher-W1 PRO or Booklet Finisher-W1 PRO)

Number of Trays: 2
Tray Capacity (with 80g/m² paper):
Upper tray: 200 sheets
Lower tray: 200 sheets

Acceptable Paper Type: Thin, Plain, Recycled, Colour, Heavy, Coated, Tracing, Bond, Pre-punched, Letterhead, Tab
Acceptable Paper Size:
SRA3, A3, A4, A4R, B4, B5, B5R
Custom size: 182 x 182mm to 330.2 x 487.7mm

Acceptable Paper Weight: 52 to 256g/m²

Power Supply: 100-240V, 50/60Hz, 1.0 A

Dimensions (W x D x H): 336 x 793 x 1 407mm (attached to the device: width excluding document tray)

Weight: Approx. 61 kg

Paper Folding Unit-J1

(Requires either the Staple Finisher-X1, Booklet Finisher-X1, Staple Finisher-W1 PRO or Booklet Finisher-W1 PRO)

Supported Folding Type: Z-Fold, C-Fold, Accordion-Z-Fold, Double Parallel-Fold, Half-Fold
Acceptable Paper Type: Thin, Plain, Recycled, Colour, Bond
Acceptable Paper Sizes:
Z-Fold: A3, A4R, B4
C-Fold, Accordion Z-Fold, Half-Fold, Double-parallel Fold: A4R

Acceptable Paper Weight:
Z-Fold, Accordion Z-Fold, C-Fold, Half-Fold: 52 to 105g/m²
Double Parallel Fold: 52 to 90g/m²

Output Capacity (with 80g/m² paper):
C-Fold/Accordion Z-Fold: approx. 40 sheets
Double Parallel-Fold: approx. 25 sheets
with Staple Finisher-X1 or Saddle Finisher-X1 (in total)
Z-Fold: A3, B4: 70 sheets, A4R: 30 sheets
Half-Fold: A4R: 30 sheets
with Staple Finisher-W1 PRO or Saddle Finisher-W1 PRO (in total)
Z-Fold: A3, B4: 60 sheets
Half-Fold: A4R: 50 sheets

Power Source: From the finisher

Dimensions (W x D x H): 336 x 793 x 1 190mm

Weight: Approx. 71kg

Card Readers

Copy Card Reader-F1
Copy Card Reader Attachment-A4

Others

Upright Control Panel-J1
Utility Tray-B1
Tab Feeding Attachment Kit-B1
Numeric Keypad-A1
Finisher Jogger Kit-A1

Device Security

iR-ADV Security Kit-AG1 for IEEE 2600 Common Criteria Certification (Available at later date)

Data Security

6.35cm(2.5inch)/250GB HDD-N1 6.35cm(2.5inch)/1TB HDD-P1

HDD Mirroring Kit-J

Print Accessories

PCL International Font Set-A1
PCL PRINTER KIT-BD1/CK1
PS PRINTER KIT-BD1/CK1
PCL Asian Font Set-A1

Barcode Printing

Barcode Printing Kit-D1

EFI-Fiery Based Controller

imagePASS-Y3 V1.1

EFI-Fiery Based Controller Options

Fiery Impose
Fiery Compose
Fiery Impose and Compose
Fiery imageViewer
Removable HDD Kit-B6

System Accessories

Copy Control Interface Kit-A1
Serial Interface Kit-K3
Connection Kit-A2 for Bluetooth LE
NFC Kit-E1

Fax Accessories

Super G3 FAX Board-AS1
Super G3 2nd Line Fax Board-AS1
Super G3 3rd/4th Line Fax Board-AS1
Remote Fax Kit-A1

Accessibility Accessories

ADF Access Handle-A1
Voice Guidance Kit-G1
Voice Operation Kit-D1

Staple Cartridges

Staple-N1
Staple-P1
Staple Cartridge-X1
Staple Cartridge-Y1
